Description
Specification
| Frame | Lite III – 6066 triple butted hydroformed aluminium. Internal cable routing. Tapered head tube, inboard disc mount, BSA BB standard, 135×9 mm QR axle. Mounts for rack, mudguards and kickstand. Max tyre size 700x35c (700x32c with mudguard) |
|---|---|
| Fork | Merida Speeder CF2; tapered; carbon; 700x35C max. tyre size |
| Gears | 20 |
| Shifters | Front: Shimano Tiagra, Rear: Shimano Tiagra |
| Front Derailleur | Shimano Tiagra |
| Rear Derailleur | Shimano Tiagra; GS |
| Bottom Bracket | Shimano BB-RS501 BSA |
| Chain | KMC X10 |
| Chainset | Shimano RS400; 50-34T; crank length: XXS-M 170 mm, L-XL 175 mm |
| Cassette | Shimano HG500; 11–32T; 10-speed |
| Brake Lever | Shimano MT200 |
| Front Brake | Shimano MT200; 2 piston; hydraulic brake with Shimano RT10; 180 mm |
| Rear Brake | Shimano MT200 / UR300; 2 piston with Shimano RT10; 180 mm |
| Grips | Merida Comp CT |
| Handlebar | Merida Expert CC; aluminium; 600 mm wide; flat |
| Stem | Merida Expert CC; aluminium; 31.8 mm diameter; 7° rise; length: XXS-XS 80 mm, S 90 mm, M 100 mm, L-XL 110 mm |
| Headset | Merida M2331 Neck |
| Pedals | VP VPE-891 |
| Saddle | Merida Comp SL; 22% recycled material; V-mount |
| Seatpost | Merida Comp CC; 30.9 mm diameter; 5 mm layback; aluminium |
| Wheel Size | 700c |
| Rims | Merida Comp SL; 17 mm inner rim width; 22 mm rim depth; aluminium; tubeless ready (tubeless tape and valves not included) |
| Spokes | Black stainless |
| Front Hub | Shimano HB-QC300; 100×9 mm; 32 spoke; Centerlock |
| Rear Hub | Shimano FH-QC300-HM; 135×9 mm; 32 spoke; Centerlock |
| Front Tyre | Kenda Piedmond Tanwall; 700x35C |
| Rear Tyre | Kenda Piedmond Tanwall; 700x35C |
| Colour | Silk Dove Blue (Blue) |
| Season | 2026 |
