Description
Frame: CF3 carbon, Nano Matrix for impact resistance.Internal cable routing, 142 x12mm axle standard, BB86 BB standard, flat mount rear brake with Disc Cooler, 1 1/2″ headtube. Fully integrated seat clamp. Max tyre size 700 x 35c (700 x 32c with mudguard)
Fork: Scultura Endurance CF3 Disc; material: carbon; 700x35C max. tyre size
Headset: Merida Team SL (SE-301 neck)
Stem: Merida Expert SL 2PII; material: aluminium; -9 degree rise; Length: (XXS-S) – 90mm, M – 100mm, (L-XL) – 110mm
Handlebar: Merida Expert SLII; material: aluminium; (XXS-S) – 380mm wide, (M-L) – 400mm wide, XL – 420mm wide
Grip: Merida Road Expert
Brake Type: Hydraulic Disc
Brake Lever: Shimano 105
Front Brake: Shimano 105; Hydraulic disc with Shimano RT54; 160mm
Rear Brake: Shimano 105; Hydraulic disc with Shimano RT54; 160mm
Front Tyre: Maxxis Re-Fuse; 700x32C; kevlar bead
Rear Tyre: Maxxis Re-Fuse; 700x32C; kevlar bead
Wheel Size: 700c
Rim: Merida Expert SL III; 23mm inner rim width; material: aluminium; Tubeless ready (tubeless tape and valves not included)
Spokes: Double Butted Black stainless
Front Hub: Shimano HB-TC500; 100x12mm; 28 Spoke; Centerlock
Rear Hub: Shimano FH-TC500-HL; 12-142mm; 28 Spoke; Centerlock
Speeds: 24
Front Derailleur: Shimano 105
Rear Derailleur: Shimano 105; GS
Shift Levers: Front: Shimano 105 disc, Rear: Shimano 105 disc
Chain: Shimano M6100-12
Cassette: Shimano 105 R7101; 11-34 teeth; 12 speed
Chainset: Shimano 105 R7100; 50-34 tooth chainset; Crank length: (XXS-XS) – 165mm, (S-M) – 170mm, (L-XL) – 172.5mm
Bottom Bracket: Shimano SM-BB71-41B; Pressfit 86.5
Pedals: Not included
Saddle: Merida Comp SL; 25% recycled material; V-mount
Seat Post: Merida Expert SL; 27.2mm diameter; in-line; material: carbon
