| Frame |
CF4 carbon front and rear, Next Generation enduro geometry, internal cable routing, long seat post insert depth. Boost axles standard, threaded BB, storage trunk, flip chip for mullet or 29er. Max tyre size – 2.5″ |
| Shock |
RockShox Deluxe Select+; lockout |
| Fork |
Marzocchi Z1; Air; 150mm travel; Tapered; 44mm fork offset; Max tyre size: 29 x 2.6″ |
| Gears |
12 |
| Shifters |
Shimano XT; Multi Release and Shimano SL-MT500-IL dropper post lever |
| Rear Derailleur |
Shimano Deore M6100 Shadow+; SGS |
| Bottom Bracket |
BB, BSA 73mm– Ø30mm, Ext. Seal |
| Chain |
KMC X12 |
| Chainset |
Race Face Turbine; 32 tooth chainset. Crank length: 170mm-S, 175mm-M up |
| Cassette |
Shimano Deore M6100; 10-51 teeth; 12 speed |
| Brake Lever |
Shimano Deore M6120 |
| Front Brake |
Shimano Deore M6120 4 piston hydraulic disc brake caliper with Shimano RT64 203mm rotor |
| Rear Brake |
Shimano Deore M6120 4 piston hydraulic disc brake caliper with Shimano RT64 203mm rotor |
| Grip |
Merida Expert EC |
| Handlebar |
Merida Team TR II; aluminium; 780mm wide; XS/S 18mm rise; M/L/XL 30mm rise |
| Stem |
Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise. Stem length: 40mm (all sizes). GoPro & Supernova mount point. |
| Head Set |
Acros ICR integrated neck; Upper and lower IPS sealing |
| Pedal |
Not included |
| Saddle |
Merida Expert SL with V-mount; including Merida minitool |
| Seat Post |
Merida Team TR; 34.9mm diameter; 10mm lay back; all sizes 30-230mm seat post travel |
| Wheel Size |
29″ / 27.5″ |
| Rims |
Merida Expert TR II; 28mm inner rim width; Aluminium; Tubeless ready (tubeless tape and valves not included) |
| Spokes |
Double Butted Black stainless |
| Front Hub |
Shimano TC500-B; 110x15mm; 32 spokes; Center lock |
| Rear Hub |
Shimano TC600-MS-B; 148x12mm, 32 spokes; Center lock. With Merida Expert TR axle including removable lever, 6/4mm allen key |
| Front Tyre |
Maxxis Minion DHF; 29″ x 2.5″; Kevlar bead, folding; TR EXO 3C MaxxTera |
| Rear Tyre |
Maxxis Dissector; 29″ x 2.4″; Kevlar bead, folding; TR EXO+ MaxxTerra |
| Colour |
Blue |
| Season |
2024 |
| Other |
Fidlock Integrated Base & TWIST Bottle 600ml |
