| Bike Geometry |
| Bottom bracket drop [mm] |
71.5 mm / 66.5 mm / 61.5 mm |
| Chain stay length [mm] |
440 mm |
| Head tube angle |
69.8° / 70.1° / 70.4° / 70.7° |
| Head tube length [mm] |
130 mm / 160 mm / 190 mm / 220 mm |
| Reach [mm] |
392 mm / 407 mm / 427 mm / 444 mm |
| Stack [mm] |
587 mm / 612 mm / 641 mm / 666 mm |
| Stand over height [mm] |
710 mm / 750 mm / 780 mm / 820 mm |
| Seat tube angle |
73.7° / 73.6° |
| Seat tube length [mm] |
450 mm / 485 mm / 525 mm / 560 mm |
| Top tube length [mm] |
563 mm / 586 mm / 615 mm / 639 mm |
| Wheelbase [mm] |
1076 mm / 1098 mm / 1126 mm / 1150 mm |
| Brake system |
| Brake Front |
Shimano GRX BR-RX400, 2 pistons, resin pad, 160 mm |
| Brake Rear |
Shimano GRX BR-RX400, 2 pistons, resin pad, 160 mm |
| Brake Mount |
Flat Mount |
| Levers |
Shimano GRX ST-RX600 Shift-Brake-Lever |
| Rotors |
Shimano SM-RT64 160 mm, Centerlock |
| Drivetrain |
| Bottom Bracket |
Shimano Tiagra BB-RS501 68/70 mm (BSA) |
| Cassette |
Shimano GRX CS-HG700-11, 11-34T |
| Chain |
Shimano GRX CN-HG601 11s SIL-TECH |
| Crankset |
Shimano GRX FC-RX600-1, 40T, 2-piece |
| Rear Derailleur |
Shimano GRX RD-RX810 11s Shadow+ |
| Pedals |
XLC Flat Pedal PD-M29 with reflectors & pins (included) |
| Shifter |
Shimano GRX ST-RX600-R shift-brake lever |
| Frame & Fork |
| Frame |
Alloy – sizes 45 / 49 / 53 / 56 (S / M / L / XL) |
| Fork |
Carbon, non-suspension |
| Max load |
120 kg |
| Kickstand mount |
KSA40 |
| Cockpit & Saddle |
| Handlebar |
XLC Gravel Bar JD-RA128A, 31.8 mm |
| Widths |
420 / 440 / 460 mm |
| Headset |
Acros ZS44/ZS56 semi-integrated |
| Saddle |
XLC Sport SA-S10, 143 mm |
| Seatpost |
XLC SP-R30, 27.2 mm, 350 mm |
| Wheels |
| Front Hub |
XLC HF-G12 12×100 mm, Centerlock |
| Rear Hub |
XLC HR-G12 12×142 mm, Centerlock |
| Rims |
XLC WR-G29 SL Disc 25/622 |
| Spokes |
DT Swiss ELEMENTAL 2.0 |
| Tyres |
Continental Terra Adventure Trail Grip, 45-622 |
| Wheel Size |
28″ Front & Rear |
