Description
Specifications:
- Super Plastic Formed lightweight aluminium frame.
- Columbus Futura Road Disc carbon fork.
- GW Tapered headset with ACB Bearings.
- 142x12mm Thru Axle rear spacing.
- 100x12mm Thru Axle front fork.
- GW ‘Switch Lever’ axles front and rear.
- Clearance for up to 30c tyres (tyre and rim dependent).
- Wireless Electronic / Mechanical / 2x / 1x Compatible.
- Not compatible with wired electronic shifting
- Front Mech clamp size needed: Braze-On.
- 68mm threaded BB.
- 31.6mm seat post required.
- Two bottle cage mounts.
- 22mm long flat mount disc brake bolts required for the frame.
- Colour: Deep Purple.
- Sizes: 47 / 50 / 53 / 56 / 59cm.
- Warranty: 5 years (for all frames purchased after Jan 1st 2019 – warranty page page for full details).
- Frame supplied with fork, headset, seat clamp, front & rear through axle, frame ports and cable guides.
- Frame Weight (with Seat Clamp, Mech Hanger and all cable guides: 1.60kg (53cm).
Due to the frame design and positioning of the front mech mount this model Aithein Disc is not compatible the following Shimano front mechs FD-5800, FD-6800 and FD-9000
